Aquatrol AT-0835BK-25T 8 x 35 Pg Pressure Tank - 2.5” T Connection, Standard Base, Black - Default Title -
by Aquatrol
SKU AT-0835BK-25T
Original price
$91.99
-
Original price
$91.99
Original price
$91.99
$91.99
-
$91.99
Current price
$91.99
AQUATROL™ PRESSURE TANKS
Aquatrol™ Pressure Tanks provide cost-effective reliability for residential and commercial applications. Available in sizes 0713 to 6383, all tanks are NSF/ANSI Standard 61 certified and backed by a 10-year warranty (6”-13”) and a 5-year warranty (14”-63”).
Benefits
- Cost effective reliability
- Easy handling & installation
- Standard & tripod base
- NSF/ANSI Standard 61 certified
- Outstanding Performance and durability
Specifications
| Max Pressure | 150 psi (10.5 bar) |
| Temperature Range | 34°F – 120°F (1°C – 49°C) |
| Vacuum Limit | 140 mmHg (5.5” Hg) |
| Cycle Test | 100,000 cycles without leaks |
| Safety Factor | 4:1 (Minimum burst at 600 psi) |
Connections, Materials
| Connections | 2.5", 4", 6" (Top, Top & Bottom, Threaded, Flange) |
| Materials | Polyethylene inner (7″–36″), FRP (40″–63″) |
| Colors | BL – Blue | BK – Black | NA – Natural |
Downloads
Data Sheet | Installation Manual
Important Notice
For water pressure use only. Not for pneumatic/hydro-pneumatic applications. Do not expose below -29°C (-20°F).
